Adding a Second Air Tank to a Train Horn: Worth It?

So you love the horn, but you want longer blasts and more honks between compressor cycles. Adding a second air tank to your train horn system is the classic upgrade for exactly that, and it’s usually simpler than people expect. Here’s what a second tank actually buys you, where the real limits are, and how to plumb it so you don’t just create a bigger leak.

What a second tank actually does

Air tanks store the pressurized air that feeds your horn. More stored air means longer blasts and more short honks before the pressure drops too low to make full sound. As a rough rule of thumb, most horns burn about 2 seconds of honk time per gallon of air. A 2-gallon tank gives you roughly 4-5 seconds of continuous honk; double that storage and you double the continuous blast.

For short honks, the math scales the same way. A 1-gallon tank at 150 psi is good for about 2-3 one-second blasts before pressure sags below the horn’s working range, while a 5-gallon tank at the same pressure delivers roughly 10-15 short blasts. Adding a second tank simply moves you up that curve.

What a second tank does not do is make your horn louder. Loudness comes from the horn design and the operating pressure, not the volume of the reservoir. If you want more decibels, that’s a different project entirely. A second tank is purely about runtime and recovery breathing room.

• Longer continuous blasts
• More short honks between compressor cycles
• The compressor cycles less often per honk session
• Extra reserve for airing up tires or air tools if you plumb it that way

The one number that decides everything: your compressor

Here’s the catch that trips up most first-timers. A single 12V compressor can only keep so much air moving. Most Viair-style compressors used in horn kits are rated to handle a system up to about 5 gallons. Stay at or under that total and one compressor is fine. Go over it, and a single compressor will struggle to recover a drained system in a reasonable time, and it may overheat trying.

The practical guidance from HornBlasters’ own tank pages is straightforward: if you have a 2-gallon tank and want to add another 2-gallon tank, you can usually do that on your existing compressor. But if you want to bolt on a full 5-gallon tank on top of what you already have, plan on a second compressor to keep up.

Why? Because the tank size a compressor is rated for reflects how much air it can realistically replenish. Adding storage without adding supply just means a longer, hotter recharge every time you drain the tanks. Recharge time depends on airflow (CFM): a Viair 380C flows about 1.84 CFM and a 444C about 2.54 CFM, so a higher-CFM unit refills a bigger system faster. Two tanks and one small compressor equals a lot of waiting.

Rule of thumb

1 compressor good to ~5 gal total

Over 5 gal total

Add a second compressor

Honk per gallon

~2 seconds

How to plumb two tanks together

The good news: connecting two tanks is mechanically simple. You run an air line between the two tanks so air can travel freely from one to the other. Once they’re linked, both tanks always sit at the same pressure, so it genuinely doesn’t matter which tank’s port you use as the outlet to your horns or accessories. Pick whichever fitting is most convenient to route.

For the connecting line, use 1/2” so airflow between the tanks isn’t choked. Two common approaches:

1. Run a length of 1/2” air line between a port on each tank. This lets you mount the tanks apart from each other, wherever they fit.
2. If you’re mounting the tanks right next to each other, thread them together directly with a hex nipple that has 1/2” NPT threads on both ends. No line needed.

A few plumbing notes worth getting right:

• Use thread sealant (PTFE tape or paste) on every NPT joint. Two tanks means twice the fittings and twice the chances for a slow leak.
• Keep the feed to the horn coming off the tank system, and keep the compressor feeding in through its check valve as before. The second tank is added storage, not a second circuit.
• Each tank still needs its own drain. Every low point where moisture collects should have a drain valve you can actually reach.

If you’re fuzzy on line sizing for the run out to the horns themselves, that’s a separate decision from the tank-to-tank link. Our air line size guide breaks down 1/4” vs 3/8” vs 1/2” for the horn feed.

Mounting: how far apart can the tanks be?

As far as you need. The two tanks don’t have to live side by side. On a truck you might tuck one in the bed and another under the frame, or split a pair to balance weight. The air doesn’t care about distance for a horn system in the range you’d ever use on a vehicle.

The only caveat is for genuinely long runs. If the line between components stretches past about 50 feet, you may want to step up to a larger line to keep airflow steady, the same way a long garden hose loses pressure over distance. That’s rarely a concern on a pickup, but it matters on a big rig, a bus, or a trailer setup.

Wherever you mount them, remember these are pressure vessels. Bolt them down to solid structure with proper brackets, keep them away from exhaust heat, and leave the drain valves accessible. Two tanks is two things that will rust from the inside if you never drain them. Our guide on how to drain a train horn air tank covers the routine.

Is a second tank actually worth it?

Honest answer: it depends on how you use the horn.

• You want long, dramatic, multi-second blasts and your compressor can’t keep up mid-session
• You already run a 2-gallon tank and adding another 2-gallon is a cheap, easy bump
• You want an onboard-air reserve for tires or tools, and the horn is a bonus
• You have real mounting space and don’t mind a little extra weight

When it’s probably not worth it:

• You mostly do quick, courtesy honks — a single tank already covers those with room to spare
• You’d have to add a second compressor and the wiring to run it, turning a simple upgrade into a full rebuild
• You’re chasing loudness — more storage won’t add a single decibel
• You have no clean place to mount and secure a second pressure vessel

For a lot of drivers, the smarter move isn’t a second tank at all — it’s a single larger tank sized right the first time, or a higher-CFM compressor so the one tank recovers faster. If you’re still deciding on capacity, start with our air tank size guide, which walks through 1, 2, 3, and 5-gallon setups and what each is good for.

Getting the pressure and duty cycle right

One more thing before you double your storage: make sure the rest of the system is set up to actually fill it. Consumer horn kits typically run in the 80-120 psi range, while authentic locomotive-style horns want 140-150 psi to sound their best. Your pressure switch should be tuned to match — a common 150-psi setup cuts the compressor in around 110-120 psi and cuts out around 145-150 psi.

Duty cycle matters more once you add storage, because a bigger system means longer compressor run times. A compressor rated at, say, a 50% duty cycle can run 30 seconds, then needs 30 seconds to cool. Ask a small compressor to fill two tanks back to back and you’ll blow past its duty cycle and cook it. This is the same reason the 5-gallon rule exists. If you’re unclear on any of this, our compressor duty cycle guide explains intermittent vs continuous ratings, and the install guide covers wiring the whole thing safely.

Bottom line

Adding a second air tank is one of the most satisfying, low-cost train horn upgrades if — and it’s a real if — your compressor can handle the extra volume. Under about 5 gallons total, one compressor and a 1/2” link between tanks gets you longer blasts and more honks with almost no downside. Push past 5 gallons and you’re signing up for a second compressor and a bigger electrical job. Match the storage to the supply, seal every fitting, keep both tanks drained, and you’ll get exactly the extra honk time you were after.

Sources

• HornBlasters — How to Add a Second Air Tank to Your Horn Kit — tank-to-tank 1/2” line and hex nipple connection, equal-pressure behavior, single-compressor 5-gallon limit, and the 50-foot line-length note.
• HornBlasters — Main Components Explained — ~2 seconds of honk per gallon, 2-gallon tank giving 4-5 seconds, and drain valve guidance.
• Train Horn Air System Sizing Guide (train-horn.com via Speedway Media) — operating pressure ranges, short-blast counts by tank size, Viair 380C/444C CFM figures, and pressure-switch cut-in/cut-out settings.
• HornBlasters — Air Tanks Collection — tank sizes and configurations referenced for onboard air.
